Infrared carbon fiber heating cable for underfloor heating(100 meters)

Pipe Heat CablesInfrared Carbon Fiber Warm Floor Hotline Heating Wire for making heating ElementProduct Details:Product Name: Carbon fiber heating wireInsulating material: Silicone rubberMax enduring temperature: 200C degreesHeating temperature: based on the using lengthHeating conductor: 12KLeakage current: 0.05mA/mThe product can withstand max power: 25W/MDiameter: 3±0.1MM(Thicker and Safer )Colors: YellowInfrared wavelength: 8UM-18UMConductor resistance: 33±10% /mHow to calculate power?Voltage*Voltage÷resistance=electric power12K=33ohm/meterFor example, using 10m 12K carbon fiber cable on 220V, the power is:220V*220V÷(10meters*33)=150WFor example,using15m 12K carbon fiber cable on 220V, the power is:220V*220V÷(15meters*33)=100WThe longerlength, the smallerpower, andlower heatingtemperature.Product Photos:(may have a little color different due to light)About this cable, we also supply red color, if you want, please review our store to find more, or contact us directly.Giving Product:Wiring:Product Applications:1. Floor heating forHome and office:Homes, villas, hotels, office buildings, hospitals, shopping malls2. Floor heating forpublic areas:Swimming pool, soccer field, gymnasium, museum, memorial hall, the kindergarten3. Floor heating for large public facilities:Bus terminal, parking lot, airport, highways4. Floor heating forprofessional field:Botanical , greenhouse, laboratoryProduct Power Calculation:Voltage * voltage / total resistance = powerFor example: 12K carbon fiber, length of 10 meters220V × 220V / (10 m x 33 Ohm) =150 wattsFor example: 12K carbon fiber length of 15 meters220V × 220V / (15 m x 33 Ohm) =100 wattsThe data showsthatthe longer heating wire you use and the smalleroutput power. (The min length of 12K carbon fiber heating wire is 10 meters)Product Advantages:1.High energy-efficient: Don't need other transmission medium, theelectrothermal conversion efficiency is above 98%.2.Comfortable and healthy: infrared floor heating, make the temperature uniformity,promote blood circulation.3.Easy to install: The carbon fiber heating wire cost a little, and has a long life span, an ==========Voltage : 81-600V(include600V)Structure : Without modular telephone connectorsUse : Not TelecommunicationHigh-concerned chemical : NoneModel Number : CF-12-Ris_customized : YesApplication : heatingType : InsulatedConductor Type : StrandedInsulation Material : RubberCertification : Product name : Carbon fiber heating wireResistance : 33 Ohm/mCore size : 12KOuter jacket : Silicone rubberDiameter : 3+-0.2 mmVoltage : 7~300VPower calculate : P=U*U/(33*L)Limited temperature : 200 cetigradeColor : Yellow
